Titanium Fasteners Manufacturer in India

Titanium Nuts Manufacturer, Titanium Bolts Price, Oldest Aerospace Titanium Fasteners Stockists, Titanium Nuts, Titanium Grade 2 Fasteners, Titanium Screws Manufacturer in India

Stud Bolt India is a prominent Titanium Nuts Manufacturer in India that specializes in supplying Titanium Bolts, Titanium Grade 2 Fasteners, and Titanium Screws at a very reasonable cost. To ensure precision engineering and superlative performance for demanding applications, one of the oldest stockists of Aerospace Titanium Fasteners, they cater to it all from ISO 9001, ASTM B348, and ASME SB348 to DIN standards to ensure strength, corrosion resistance, and durability. Aerospace, marine, medical, chemical processing, and automotive use these Titanium Fasteners that withstand extreme environments.

Allen Cap Bolts Supplier, Titanium Square Bolts, Titanium Flange Bolts, Titanium Threaded Rod, Titanium Socket Head Cap Screw, Titanium Grade 2 Hex Bolts Supplier in India

Stud Bolt India is the biggest Titanium Allen Cap Bolts Supplier in India, a trusted supplier of high-quality Titanium Square Bolts, Flange Bolts, Threaded Rods, Socket Head Cap Screws, and Grade 2 Hex Bolts. Our carrier screws are manufactured in sizes ranging from M3 to M64 with lengths from 10mm to 500mm for bolt-type projects and up to 6000mm for threaded rods to deliver an exact fit for diverse industrial applications. Chemical composition analysis (ASTM E1409) and mechanical tests (ASTM E8/E8M) for tensile strength, yield strength, hardness, and corrosion resistance ensure high performance.Hastelloy Fasteners in India.

Types Of Titanium Fasteners

Titanium Nuts

Titanium Bolts

Titanium Screw

Titanium Washers

Titanium Stud Bolts

Titanium Threaded Rod

Specifiacation of Titanium Fasteners

Specifiacation
Specifications	ASME SB348/ ASTM B348
Standard	DIN, ASTM, BS and all other International Standards
Grades	Grade 5, Grade 2
Length	3 mm - 200 mm
Machine Screws Size	M1.6 to M12
Bolts Size	M3 to M56 \| 3/6" - 2" \| Custom Sizes
Nuts Size	M3 to M56 \| 3/6" - 2" \| Custom Sizes
Washers Size	M3 to M56 \| 3/6" - 2" \| Custom Sizes
Types	Hex Bolts, nut, studs, threaded rod, screws, washer, socket head cap screw

Titanium Fasteners Mechanical Properties

Grade	Tensile Strength (min)	Yield Strength 0.2% Offset	Elongation in 2 inch or 50mm % (min)
KSI	MPa	KSI	MPa
Gr.1	35	240	20 – 45	138 – 310	24
Gr.2	50	345	40 – 65	275 – 450	20
Gr.3	65	450	55 – 80	380 – 550	18
Gr.4	80	550	≥70	≥483	15
Gr.5	138	950	≥128	≥880	14
Gr.7	50	345	≥40	≥275	24
Gr.9	125	860	≥105	≥725	10
Gr.12	70	483	≥50	≥345	18
Gr.23	125	860	≥115	≥790	15

Titanium Fasteners Chemical Composition

ASTM Grade	Manganese	Carbon	Silicon	Phospherous	Sulfur	Chromium	Nickel	Molybdenum	Other
304	2.00 max	0.08 max	0.75 max	0.045 max	0.030 max	18.0-20.0	8.0 11.0	-	-
316	2.00 max	0.08 max	0.75 max	0.045 max	0.030 max	16.0-18.0	10.0 14.0	2.0 3.0	-
317L	2.00 max	0.035 max	0.75 max	0.045 max	0.030 max	18.0-20.0	11.0 14.0	3.0 4.0	-
310 S	2.00 max	0.08 max	1.5 max	0.045 max	0.030 max	24.0-26.0	19.0 22.0	3.0 4.0	-
347 H	2.00 max	0.04 0.10	0.75 max	0.045 max	0.030 max	17.0- 19.0	9.0 13.0	-	10C(Cb+Ta)<1.10%
321	2.00 max	0.08	0.75 max	0.045 max	0.030 max	17.0-20.0	9.0 12.0	-	5C 0.70%

Size Chart for Titanium Fasteners

Titanium Bolt Type	SIZE	PROPERTY CLASS	TENSILE STRENGTH	STANDARD
Titanium Hex Head Bolt / Screws	M4 to M80	10.9	1040N / mm2 min	ISO 4017 (Full Thread) ISO 4014 (Half Thread)

,, “ Titanium Fasteners Manufacturer & Supplier in India” Stud Bolt India

Get in touch

Whatsapp

+91 91723 33437

Call

+91 91723 33437

Mail address

export@pearlshims.com

Packaging of Titanium Fasteners

Fasteners are securely packed in durable materials like plastic bags, cartons, or wooden crates to prevent damage and ensure safe transportation. Custom packaging options are available for bulk orders, ensuring easy handling and protection during transit.
